ManufacturerBaader Planetarium
SKU (#)2961331
EAN Code4047825047601
Net weight (kg)0.09
ColourBlack
Transmission RangeH-alpha
Filter Thickness (without cell)3 mm
HBW (Half bandwidth)3.5 nm
CWL (Central Wavelength)656,3 nm
AR-CoatingReflex-Blockerâ„¢ hard coated, Plane-optically polished
Special FeaturesCMOS-optimized with Life-Coatâ„¢\n
Filter size65 x 65 mm
Filter UsageCMOS, CCD, H-alpha
Filter mountedUnmounted
Type of FilterUltra-Narrowband
Single or Set?Single Filter
Filter shapesquare
","image":["/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-1.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-2.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-3.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-4.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-5.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-6.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-7.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-8.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-9.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-10.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-11.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-12.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-13.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-14.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-15.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-16.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-17.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-18.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-19.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-20.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-21.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-22.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-23.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-24.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-25.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-26.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-27.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-28.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-29.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-30.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-31.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-32.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-33.jpg","/images/eyepiecehouse.shop/images/product/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized-34.jpg"],"sku":"baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized","brand":{"@type":"Brand","name":"Telescopes"},"offers":{"@type":"AggregateOffer","lowPrice":71.59,"highPrice":160.75,"priceCurrency":"USD","availability":"https://schema.org/InStock","url":"https://eyepiecehouse.shop/products/baader-h-alpha-ultra-narrowband-filters-3-5nm-cmos-optimized","offerCount":7}}
HomeStore

Baader H-alpha Ultra-Narrowband-Filters (3.5nm) – CMOS Optimized

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6
Product image 7
Product image 8
Product image 9
Product image 10
Product image 11
Product image 12
Product image 13
Product image 14
Product image 15
Product image 16
Product image 17
Product image 18
Product image 19
Product image 20
Product image 21
Product image 22
Product image 23
Product image 24
Product image 25
Product image 26
Product image 27
Product image 28
Product image 29
Product image 30
Product image 31
Product image 32
Product image 33
Product image 34

Baader H-alpha Ultra-Narrowband-Filters (3.5nm) – CMOS Optimized

Highlights

  • Baader H-alpha Ultra-Narrowband Filter – Premium Grade
  • 3.5 nm FWHM (to harmonize the exposure time with O-III / S-II), recommended for optical systems from f/10 to f/3.5
  • For highest contrast even at strongest light pollution, minimizes star size, emphasizes finest nebula detail – indispensable under Bortle 9/8/7/(6) skies
  • Reflex-Blockerâ„¢ hard coated and Plane-optically polished – with sealed coating edges (Life-Coatâ„¢)
  • Blackened edges all around, with filter-lead-side-indicator in the form of a black front side outer rim
  • Optimized for modern CMOS cameras, but excellent for CCD camera technologies

We explicitly warn against observing the sun with a DeepSky 6.5 nm (equivalent to 65 Angstrom) H-alpha narrowband filter, specialized solar chromosphere and prominence filters from SolarSpectrum start at 0.8 Angstrom. Photographic experiments with a camera are theoretically possible, but by no means observe the sun with naked eyes – you endanger your eyesight!

This new generation of Baader CMOS-filters features:

CMOS-optimized Baader Filters



  • Increased contrast
  • Ever more narrow band-passes
  • Reflex-Blocker™ coatings, for largest ever freedom from halos, even under most adverse conditions concerning aux-optics
  • FWHM on each filter category carefully designed to allow for 1:1:1 exposures, matched for typical CMOS quantum efficiency and s/n ratio
  • Identical filter thickness to existing standards, with utmost care for remaining Par focal
  • Blackened edges all around, with filter-lead-side-indicator in the form of a black front side outer rim, to additionally eliminate any reflection due to light falling onto the edge of a filter
  • Each filter coated individually, with sealed coating edge (NOT cut out of a larger plate with coatings left exposed, read more)
  • Life-Coatâ„¢: evermore hard coatings to enable a non-aging coating for life – even in a most adverse environment

    • WE FOUND THE WAY
    New CMOS-optimized Baader (Ultra-)Narrowband and High-speed Filters

    Specifications

    Manufacturer Baader Planetarium
    SKU (#) 2961331
    EAN Code 4047825047601
    Net weight (kg) 0.09
    Colour Black
    Transmission Range H-alpha
    Filter Thickness (without cell) 3 mm
    HBW (Half bandwidth) 3.5 nm
    CWL (Central Wavelength) 656,3 nm
    AR-Coating Reflex-Blockerâ„¢ hard coated, Plane-optically polished
    Special Features CMOS-optimized with Life-Coatâ„¢
    Filter size 65 x 65 mm
    Filter Usage CMOS, CCD, H-alpha
    Filter mounted Unmounted
    Type of Filter Ultra-Narrowband
    Single or Set? Single Filter
    Filter shape square
    Select Size
    From $71.59

    Original: $204.54

    -65%
    Baader H-alpha Ultra-Narrowband-Filters (3.5nm) – CMOS Optimized—

    $204.54

    $71.59

    Product Information

    Shipping & Returns

    Description

    Highlights

    • Baader H-alpha Ultra-Narrowband Filter – Premium Grade
    • 3.5 nm FWHM (to harmonize the exposure time with O-III / S-II), recommended for optical systems from f/10 to f/3.5
    • For highest contrast even at strongest light pollution, minimizes star size, emphasizes finest nebula detail – indispensable under Bortle 9/8/7/(6) skies
    • Reflex-Blockerâ„¢ hard coated and Plane-optically polished – with sealed coating edges (Life-Coatâ„¢)
    • Blackened edges all around, with filter-lead-side-indicator in the form of a black front side outer rim
    • Optimized for modern CMOS cameras, but excellent for CCD camera technologies

    We explicitly warn against observing the sun with a DeepSky 6.5 nm (equivalent to 65 Angstrom) H-alpha narrowband filter, specialized solar chromosphere and prominence filters from SolarSpectrum start at 0.8 Angstrom. Photographic experiments with a camera are theoretically possible, but by no means observe the sun with naked eyes – you endanger your eyesight!

    This new generation of Baader CMOS-filters features:

    CMOS-optimized Baader Filters



  • Increased contrast
  • Ever more narrow band-passes
  • Reflex-Blocker™ coatings, for largest ever freedom from halos, even under most adverse conditions concerning aux-optics
  • FWHM on each filter category carefully designed to allow for 1:1:1 exposures, matched for typical CMOS quantum efficiency and s/n ratio
  • Identical filter thickness to existing standards, with utmost care for remaining Par focal
  • Blackened edges all around, with filter-lead-side-indicator in the form of a black front side outer rim, to additionally eliminate any reflection due to light falling onto the edge of a filter
  • Each filter coated individually, with sealed coating edge (NOT cut out of a larger plate with coatings left exposed, read more)
  • Life-Coatâ„¢: evermore hard coatings to enable a non-aging coating for life – even in a most adverse environment

    • WE FOUND THE WAY
    New CMOS-optimized Baader (Ultra-)Narrowband and High-speed Filters

    Specifications

    Manufacturer Baader Planetarium
    SKU (#) 2961331
    EAN Code 4047825047601
    Net weight (kg) 0.09
    Colour Black
    Transmission Range H-alpha
    Filter Thickness (without cell) 3 mm
    HBW (Half bandwidth) 3.5 nm
    CWL (Central Wavelength) 656,3 nm
    AR-Coating Reflex-Blockerâ„¢ hard coated, Plane-optically polished
    Special Features CMOS-optimized with Life-Coatâ„¢
    Filter size 65 x 65 mm
    Filter Usage CMOS, CCD, H-alpha
    Filter mounted Unmounted
    Type of Filter Ultra-Narrowband
    Single or Set? Single Filter
    Filter shape square
